Traverse Systems

Model Installer

The Model Installer is able to pickup a model from a cart, move it to the balance, and install it. And vice versa. During testing, the model installer is collapsed and raised above the wind flow.

The model installer has 3 axes for positioning the Claw:

· Xmi

· Ymi

· Zmi.

The Zmi is physically a tilt function. By compensation in the Y-direction, a vertical Z move is  achieved.

The model is lifted in 4 points, located underneath the bottom of the model.

The Model Installer operates in a Semi-automated mode, where it moves in predefined sequences. The automation is based on laser signals for ensuring that the model is in place before executing a lift.

The geometry of each model is saved in a file. When a new model is loaded in the GUI, the predefined sequences are adjusted to the geometry of that particular model.

Text Box: Z
Text Box: Y

Claw

X Carriage

Tilt

Specifications for Model Installer

Accuracy:



± 1 mm

Repeatability:



± 0.05 mm

Max. load:



25 kg

Time from cart to balance:



30 s

Range:

X:

3.7 m



Y:

5.453 m



Z:

2.535 m

Speed:

X:

285 mm/s



Y:

285 mm/s



Z:

40 mm/s
